Garage Door Sensor

Is it open? Ever wonder if your garage door is open? This project uses a simple tilt sensor to let you know! It turns a light on or off based on the sensor’s position. It also triggers Google Home to announce things like “The garage door is open.”

📐 Project Diagram

Notes:

• The diagram shows a speaker representing a Google announcement.
• The light after Google is a smart plug.
• The Zigbee hub is a device paired into Google Home automation.
• The tilt sensor is a simple device that detects the angle of the garage door.
• The Zigbee hub receives the sensor signal and passes it to the Smart Life (Tuya) integration paired with Google Home.
• Google Home processes the signal and triggers the light and an announcement that the door is open or closed.
• The bedroom light turns on or off depending on the door state.

🧰 Parts List

• Smart Life app (Android) — Tuya works similarly.
• Zigbee hub compatible with Google Home (mine is an “M6 Matter & Zigbee Hub”).
• Tilt sensor (e.g., THIRDREALITY Zigbee Smart Garage Door Tilt Sensor).
• Smart plug (e.g., Kasa Smart Plug Mini by TP-Link).
• Google Home / Nest speaker or display.

💡 Code

No code required. Set up the automation in Google Home / Smart Life.

🔍 How It Works

When the garage door opens, the tilt sensor notifies the Zigbee hub, which relays the state to your Smart Life ↔ Google Home setup. Google Home then announces the state and toggles a smart plug (bedroom light) so you have both audio and visual confirmation.

So when I walk into my bedroom and the light is on I know the garage door is open.

This project is a great example of how you can integrate various smart home devices to create a more automated and responsive living environment.
